Diverter Valves: J-200 Series
from $0.87
J-280 Models (2007+)
2540-239, T-Valve: Cap And Knob
2540-274, T-Valve: Knob
2540-273, T-Valve: Cap
6541-241, O-Ring: Stem
6541-240, O-Ring: Body
6541-242, Gate Valve (T-Valve)
2540-275, Fitting: Wall T-Valve (6541-238 Nut Included)
6541-238, Nut: Diverter
6541-236, Body Assembly: T-Valve (Includes one each of items 4 through 6 above)
J-210 (2005+)
A 6541-800, Jet Face: Divert-A-Jet (Graphite Color for 2012+ J-210 Models) B 6540-800, Jet Face: Divert-A-Jet (Gray 2011 And Older Models)
6540-797, Wall Fitting: Divert-A-Jet
6540-511, O-Ring: Divert-A-Jet
6540-798, Nut: Divert-A-Jet
6540-796, Jet Back: Divert-A-Jet
Jet Assemblies: J-200 Series
from $0.57
Compatible with:
J-210 2012+
J-215 2016+
J-225 2016+
J-235 2014-2019
J-245 2014-2019
J-275 2014-2019
J-280 2014-2019
2540-261, Jet Face: 200s Micro (DX Jet, Grey)B 2540-265, Jet Face: 200s Micro (DX Jet, Stainless Steel)
2540-255, Jet Face: 200s Accu Pressure (DL Jet, Stainless Steel)
2540-245, Jet Face: 200s Pulsator (DV Jet , Stainless)
6541-576, Jet Face: Classic PRO Pulsating
6541-577, Jet Face: Classic PRO Accu Pressure
6541-612, Jet Back: 200s (Nut And O-Ring Included)
6540-854, O-Ring: 200s
6541-614, Washer: 200s (Self Leveling)
Hi-Limit Sensors
from $20.95
Note: Not all hi-limit sensors may be in stock and delivery times may be delayed. Hi-limit sensors are non-refundable/non-returnable.
Use the chart below to determine which hi-limit sensors are compatible with your hot tub. Please note: all hi-limit sensors except 6600-168 are used for LED top-side controllers. If your J-300 series has an LCD controller, do not use an LED hi-limit sensor. Please contact or chat with us if you are unsure.
6600-140, Sensor: Hi-limit LED Series with Connector; Includes Curled Finger Contacts (32" cable)
6600-144, Sensor: Hi-limit LED Series without Connector; Includes Curled Finger Connectors (32" Cable)
6472-525, Harness: Hi-Limit LX 2-Pin (32" Cable)
6600-179, Sensor: Hi-limit J-400 Series (DSMT Connector for J-1000) (37" Cable)
6600-110, Sensor: Hi-limit with Box End Connectors (90" Cable)
6600-129, Sensor: Hi-limit J-300/J-200 LED with Curled Finger Connectors
6600-168, Sensor: Hi-limit J-300/J-400 LCD with Box End Connectors
6000-093, Sensor: Hi-limit Disc ( All models)
6600-140
6600-144*
6472-525
6600-179
6600-110
6600-129**
6600-168 (LCD)
J-LX/J-LXL
2011+
2011+
J-500 Series (all)
2015+
J-400 Series (all)
Sept 2015+
2010-Aug 2015
2006-2009
2006-2009 LCD
J-300 Series (all)
2016+
2002+ LCD
J-310
2002-2003
2002-2003
J-315
2013-2016
2004-2017
2004-2015
J-320
2002-2003
J-325
2013-2016
2004-2017
2004 & 2008 & 2012-2015
J-330
2002-2003
J-335
2013-2016
2004-2017
J-340
2002-2003
J-345
2013-2016
2004-2017
J-350
2002-2003
2002-2003
J-355
2013-2016
2007-2017
2004-2006
2004-2006
J-360
2002-2003
2002-2003
J-365
2013-2016
2007-2017
2004-2006
2004-2006
J-370
2002-2003
2002-2003
J-375
2013-2016
2007-2017
2004-2006
2004-2006
J-380
2002-2003
2002-2003
J-385
2004-2006
2004-2006
J-200 Series (all)
2018+
J-210
2012-2017
2005-2017
J-220
2005-2017
J-230
2012-2017
2005-2017
J-235
2012-2017
2012-2017
J-245
2012-2017
2012-2017
J-270
2012-2017
2007-2017
J-275
2012-2017
2012-2017
J-280
2012-2017
2007-2017
J-100 Series (all)
2012-2017
2018+
Del Sol
All
*Can use 6600-140**Can use 6600-144
LED Perimeter Pin Lights
from $0.57
Compatibility:
06/2014+ 680 McKinley and Ramona
2013+ 680 Edison
2012+ 680 Peyton
1. 6560-581, Lens, Bullet 1"
2. 6541-433, Washer: .95 OD x .40 ID x .075 (replaced 6540 -368 8.31.20)
3. 6540-384, Nut: 3/8-16 Hex
4. 6541-000, O-Ring: .285"O.D. Replaces part number 6541-688 above
5. 6541-689, Nut: Compress Hex Dome
6541-647, Pin light with nut (limited stock)
6541-648, O-ring (limited stock)
6540-368, Washer: 0.9"O.D. x 0.4"I.D. x 0.075"(Silicone Rubber) (replaced by 6541-433)
6541-688, O-Ring: 5/16"O.D. (replaced by 6541-000)
6560-558, Light: LED Quad 36"x 38"Daisy (2012+ J-280, J-275, J-270, J-245, J-235 Models Only)
Pillow: Jacuzzi J-LX Collection
from $54.95
Jacuzzi Brand Pillow for J-LX Collection.
2472-006
Replaces: 6455-485
Waterfalls: J-300/J-200/J-100 Series
from $0.41
Waterfall Returns
J-LX, J-500, J-300, J-200, J-100 Series
6540-979, Drain: Gravity Drain with Cover 1-1/32"?
6540-682, O-Ring, 1.22" ID X 1 0.158" C/S (2 Req'd.)
6540-685, Nut, Accu- Pressure Jet
Waterfalls (J-200/J-100 Series)
6540-925, Cover: Waterfall Gray (Plastic)
6000-530, Cover: Waterfall (Stainless Steel)
6540-921, Fill Spout: Waterfall (Clear Plastic)
6541-285, Gasket: Waterfall
6570-121, Washer: Split Lock, 5/16" Stainless Steel (2 Req'd.)
6570-120, Bolt: Hex 1/4-20 x 1", Stainless Steel (2 Req'd.)
2540-004, Adapter: 3/4" Slip x FPT
6540-262, Adapter: 3/4" Spigot x 3/4" Barb
Air Components: J-400 and J-500 Series
from $0.57
Air control valves are available for sale for the J-400 Series by Jacuzzi® Hot Tub. The air control valve is suitable for all hot tub models, but the part number will change depending on the model: individual air control components and their specifications are listed below:
J-400 Air Components (2006+)
Air Control Valve (All J-435, J-445, J-475, J-485, & 2020+ J-425, J-495)
6541-142, Control: Air Toggle Switch
6541-143, Gasket: Toggle Outer Shell
6541-144, O-Ring: Toggle Inner Shell
6540-375, Manifold: Air Control Jacket
6540-911, Nut: Push Button Air Control
6540-910, Elbow: Push Button Air Control
Air Control Valve (All other J-400 Models)
20101-001, Knob: Air Valve
6540-377, Control: Air Body And Stem
6540-522, O-Ring: EPDM, 1.64" ID x 0.163"
6540-375, Manifold: Air Control Jacket
6540-376, Nut: Air Control
6000-179, Knob Stem
6000-016, Cup (Long)
6000-029, O-Ring
Filter/Skimmer Air Bleed Line
20216-001, Check Valve: 3/4" Air
6540-024, Adapter: 1/2" Spigot x 3/8" Barb
6570-491, Clamp: Metal Hose (Black)
IX Jet Air Bleed Check Valve
20216-001, Check Valve: 3/4" Air
6540-065, Adapter: 1" Spigot x 3/4" Barb
6570-033, Clamp: 27mm
J-400 Air Bleed Line (2009+)
6540-252, Nut: Air Injector
6540-228, O-Ring: EPDM 0.662" ID x 0.210"
6541-263, Injector: Air PVC Gray
J-500 Series Air Components (2015+)
6541-142, Control: Air Toggle Switch
6541-143, Gasket: Toggle Outer Shell
6541-144, O-Ring: Toggle Inner Shell
6540-375, Manifold: Air Control Jacket
6540-911, Nut: Push Button Air Control
6540-910, Elbow: Push Button Air Control
J-500 Air Bleed Line Fitting (2015+)
6540-252, Nut: Air Injector
6540-228, O-Ring: EPDM 0.662" ID x 0.210"
6541-263, Injector: Air PVC Gray
PowerPro LX Jet
from $4.34
2540-366, Jet Face: PowerPro LX w/316SS Escutcheon, 2007+ 6541-470, Jet Face: PowerPro LX w/o 316SS Escutcheon, 2007+6540-760, Jet Face: PowerPro LX, 2002-2006 6000-363, LX Jet Face Conversion Kit (Not Shown) 5-1/4"
6540-761, Jet Back: PowerPro LX, 2002+
6541-472, Jet Back: Power Pro LX, 2007+
6541-394, O-Ring: Triple 3.42 I.D
6540-763, Washer: Self Leveling PowerPro LX
6540-762, Nut: PowerPro LX, 2002+,
6541-471, Ring: PowerPro Jet Back Adapter (Adapts older 2006 Jet Backs 6540- 760 and 6540-761 above to accept current 2007+ Jet Faces 2540-366 and 6541-470).
Jet Assemblies: Mini PowerPro FX/FX-1 Jet (2/2004+)
from $1.30
Compatible with:
J-LX/LXL Series 2015-2019
J-315 2016+
J-325 2016+
J-355 2014+
J-345 2014+
J-355 2014+
J-365 2014+
J-375 2014+
J-385 2016+
J-415 2014-2019
J-425 2016-2019
J-435 2018+
J-445 2018+
J-465 2016-2017
J-470 2016-2018
J-475 2019+
J-480 2016-2018
J-485 2019+
J-495 2016+
J-575/585 2015+
1a. 6541-170, Jet Face: Mini PowerPro FX-1 PC with Stainless Steel Escutcheon, 2015+ (Dark Gray)1b. 20285-001, Jet Face: Mini PowerPro FX with Stainless Steel Escutcheon (Light Gray - 2/2004 - 2014)
6540-555, Jet Face: Mini PowerPro FX without Stainless Steel Escutcheon (See Note)
6540-556, Jet Back: Mini PowerPro FX
6541-098, O-Ring: EDPM 1.98" I.D. x 0.163", Double
6540-639, Washer: Self Leveling Mini PowerPro FX
6540-557, Nut: Mini PowerPro FX, 2004+
Low Flow Circulation Pump / Replacement Kit
from $0.37
Individual Circulation Pumps For J-300 Non-Convertible Spas (2002-2011)All J-280/J-270/J-230 Non-Convertible Spas with The Circ. Pump Option (2002-2011)
6000-125E (Laing) or 6000-125NA (Grundfos), Circulation Pump: E10, 240V 50/60Hz with Cord. This pump replaces retired 6000-125, 6500-035 pumps.
6500-460 (Laing)or 6500-460NA (Grundfos), Circulation Pump: E10, 120V with Chord. This pump replaced retired 6500-038 pump.
Note: The following parts are recommended when replacing a 6500-125 low-flow circulation pump. These products are also known as kit 6000-125RK (Grunfos pump + installation kit). They can be ordered as a kit or individually.
Recommended quantities:
2x 27mm clamp (6570-033)
2x #6 x 1" Flat Head Wood Screw (6570-100)
1x 3/4" Barb x Barb adapter (6541-075)
1x 3/4" Barb x Barb elbow (6540-228)
3x 3/4" Clear PVC Hose (sold by the foot for a total of 3') (6540-744)
J-300/J-200 Pump Replacement Parts (Prior to June 2009)
from $0.71
*Parts on this page may not be in stock and may be delayed for shipment
J-300/J-200 Fixed Bracket 48 Frame (60Hz) Pump Replacement Parts (Prior to June 2009)
6000-031, 2" Split nut6500-232, 2" Straight Union Assembly (includes 2" O-ring)6500-037, 2" 45° Union Assembly (includes 2" O-ring)6500-288, Front Housing for 2.5 hp (all years) and 2.0 hp (July 2003 - December 2009)6500-287, Font Housing for 2.0 hp (1999-June 2003) No longer available6540-171, 1/4-18 NSPM threadx 3/8"Barb, Stainless Steel Adapter (replaces 6540-030) Requires 1x 6540-171 O-ring (below)6540-263, O-ring (0.434" IDx 0.682" OD x 0.125" )6570-070, Self-tapping screw6500-255, Drain plug (1/4" NPSM)6500-256, Drain plug o-ring (0.47" ID x 0.103" )6500-290, Front Housing O-Ring6500-281, Seal (2.0hp 0.625" Shaft, PS200, 2002-June 2006) 6500-805, Seal (2.5hp 0.75" Shaft, PS201, all years) 6500-286, Rear bracket (2.0hp 1999-June 2003) No longer available6500-311, Rear bracket (2.0hp July 2003+, 2.5hp all years)Impellers6500-295, Impeller for 2.5hp (4.129" Diameter)6500-296, Impeller for 2.0hp (3.875" Diameter)6500-309, Impeller for 2.0hp (5.025" Diameter)6500-308, Impeller for 1.5hp (3.65" Diameter) No longer available
Compatibility:
6500-707 (2-Speed),
6500-753 (2-Speed),
6500-754 (2-Speed),
6500-758 (2-Speed),
6500-759 (2-Speed),
6500-761 (2-Speed),
6500-769 (1-Speed),
6500-763 (1-Speed)
North American 60Hz High-Flow Circulation Pumps
from $0.41
Compatible with
All J-LX & J-LXL Models (2011+)
All J-500 Models (2015+)
All J-400 models except J-415 (Jan 26, 2012+)
J-415 Models (October 2, 2013+)
J-385, J-375, J-365, J-355 Models (2012+)
J-345, J-335 Models (2012-8/11/15)
6500-907S, LX Pump: 240V 60Hz, 48 Frame, 3'Oclock (1.5" Unions); 13.7" overall length
Mounting Hardware (All Models) 6570-011, Insulator: 1" x 1.5" Rubber (4 Required)
6570-126, Nut: Hex 5/16-18 (4 Required)
6570-127, Washer, Split-Lock 5/16 (4 Required)
400 Series Skimmer Weir
from $20.95
Replacement floating skimmer weir.
Compatibility:
2006-2011: All J-400 Series Hot Tubs
2006-2012: J-480, J-470, J-465
6000-625, Skimmer: Weir Long
6540-845, Weir: Float J-400 (Attaches to Skimmer Weir)
2540-049, Basket: Skimmer J-400
6000-579, Vent Ring, Hi-Flow Cartridge Filter
20069-001, Long Canister: 23.5" with Nut (Fits J-480, J-470, And 5/07+ J-465 Models); Weir Purchased Separately Above
6541-189, Short Canister: 18.5" with Floating Weir And Nut (Fits J460 and 1/07- 4/07 J-465 Models)
Pillow Parts: J-300 (2016-2020+)
from $0.85
2016 - 2019
6455-486: Fastener J-300 Pillow with a plastic push-in screw (2 required)
2020+:
6540-543: Grommet (2 per pillow) and requires 6540-547
6540-547: Wingnut for grommet (2 per pillow) used with 6540-543
Also compatible with: J-445/J-435 (Oct 2017+), J-485/J-475 (2019+) and all J-400 (2020+)
J-300/J-200 North America 60Hz Bracketless
from $26.95
6500-341S Universal Bracket Mount, 1-Speed
6500-343S Universal Bracket Mount, 2-Speed
6000-031 Nut: Split Replacement 2"
6500-232 Union: Assembly 2" (Straight)
6500-037 Union: Assembly 2" (45°)
6000-645 O-Ring: 2"
6540-171 Adapter, 1/4-18 NSPM thread x 3/8" Barb, Stainless Steel
6540-263 O-Ring, 0.434" ID x 0.682" OD x 0.125"
6500-546 Housing: Front
6500-548 Screw: Self-Tapping
6500-547 Plug: Drain And O-Ring
6500-545 O-Ring: Front Housing
6500-549 Impeller, 2.5hp6500-550 Impeller, 2.0hp6500-551 Impeller, 1.5hp
6500-543 Seal (Stationary) ASM-PS200
6500-544 Seal (Rotating) ASM-PS200
6500-540 Housing: Rear Bracket
6500-449 Start Capacitor, 240V
6500-448 Start Capacitor, 120
